Niphan Marine Plugs & Sockets
The C4 compact plug and socket offers a robust and reliable connector suitable for hostile and demanding environments.
- Simple to install and rewire
- Operating temperature range from -40 to +160 ºC
- Shock and vibration resistant
- Corrosion resistant
- IP66 rated
- PMC, low smoke and toxicity insulation material
- Halogen and Cadmium free
Electrical rating:
- Up to 100 Amps
- Up to 500 Volts AC
- Sprung contacts suitable for +1000 insertions
- Contact configuration – 3 pole +earth
- Ship and shore mounted marine cranes & grabs
- Shore power supplies – docks and dry docks
- Hostile and demanding environments
Features and Benefits
The C4 compact plug and socket offers a robust and reliable connector suitable for hostile and demanding environments.
- Simple to install and rewire
- Operating temperature range from -40 to +160 ºC
- Shock and vibration resistant
- Corrosion resistant
- IP66 rated
- PMC, low smoke and toxicity insulation material
- Halogen and Cadmium free
Range
Electrical rating:
- Up to 100 Amps
- Up to 500 Volts AC
- Sprung contacts suitable for +1000 insertions
- Contact configuration – 3 pole +earth
Applications
- Ship and shore mounted marine cranes & grabs
- Shore power supplies – docks and dry docks
- Hostile and demanding environments
LPA Connection Systems is a leading electro-mechanical engineering company, based in the UK. With over 100 years of engineering experience and expertise, LPA provides an extensive range of electrical connector products and connection systems.
