ARINC 404 Connectors
Arinc 404 rack and panel connectors are designed to meet or exceed the requirements of MIL-C-81659 and ARINC Specification 404.
The series is a multi-purpose connector used in aerospace, military, and computer periphery applications and others. These connectors are available in five shell styles with up to four insert cavities. Insert arrangements are available utilising a single type contact or a combination of standard and coaxial contacts.
Application specific designs including transient protection are available.
- Wide range of insert options
- Operating temperature range of -55°C to +125°C
- Aluminium shells with various plating options
- Non-environmental and environmental sealed connectors are offered
- 500 mating cycles
- Salt spray resistant to Mil STD 1344 Method 1001 Cond B
- Vibration to Mil STD 1344 Method 2005 Cond IV
- Metallic contact retention clips
- 14 different inserts available
- Coax, twinax or triax, fibre, quadrax options available
- Various mounting methods
- Multiple keying options
- Aerospace
- Military
- Power generation
- Industrial
- Mass transit
- Railway
Features and Benefits
- Wide range of insert options
- Operating temperature range of -55°C to +125°C
- Aluminium shells with various plating options
- Non-environmental and environmental sealed connectors are offered
- 500 mating cycles
- Salt spray resistant to Mil STD 1344 Method 1001 Cond B
- Vibration to Mil STD 1344 Method 2005 Cond IV
- Metallic contact retention clips
Range
- 14 different inserts available
- Coax, twinax or triax, fibre, quadrax options available
- Various mounting methods
- Multiple keying options
Applications
- Aerospace
- Military
- Power generation
- Industrial
- Mass transit
- Railway
